API Architecture – Distinguish between Web Application and API

A RESTful service is a common element in any modern system. But not all the RESTful service implementations are valid Web APIs. This first post of the API architecture series, covers the idea of separation of an API from the web application based RESTful implementations.

Often we see a figure analogous to the one below in many diagrams. Regardless of what the diagram is called, if we look at this figure the direct meaning it gives, is the separation of the API and the clients.

client and api

In web development, a Javascript client talks to the RESTful endpoints designed specifically for it. There’s nothing wrong in this implementation, it is perfectly fine, but the concern is – the system does not have an API. Having mere technical implementation of a RESTful service does not create an API.

In order claim an API based architecture, the RESTful service implementation should have the following characteristics.



#1 Individually deployable

API assemblies should be deployable in a separate instance without the consuming client. Often Javascript clients are deployed together with the RESTful service, because these clients are often developed along with the API. Separate deployment model gives the benefit of scaling the API when required.

#2 Stateless or centralized state management

APIs should be either stateless and get the state information from the client request or should contain a centralized state persistence. Centralized state cache is often an in-memory caching implementation like Redi.

#3 Avoid Client Commanded Implementations

I strongly advocate this point, developers sometimes tend to do this if they find performing the required view model construction in the client is not preferable. It is hard to draw the boundary, because some aggregate operations are better be performed in the server but some cases are pure violations, Example – assume an endpoint has response body like the below JSON payload.


{

id : 1,

firstName : "Thurupathan",

lastName : "Vijayakumar"

}

And having another endpoint just for the purpose of another view which has a response output like the following JSON payload is a violation.


{

id : 1,

fullName : "Thurupathan Vijayakumar"

}

The above example is a very simple one, but I have seen worst implementations that API has responses of color codes and CSS classes, where the reason was purely that developers did not want to write code in Javascript. I would call such cases as client commanded implementations.

(Back end for front end) BFF model implementations have different response messages based on the client, but that is different from view model construction. Also the features like sorting and pagination are not part of the view model construction.

#4 No cookies

A RESTful service which is exposed as an API should NOT accept any information in the cookies. This again happens with the tight coupling of web application with the RESTful service. Developers create a cookie and the consequent request from the Javascript clients to the RESTful service sends the information from the cookies. All data from client to the API should be in query string, request body or in HTTP headers.

#5 Documentation

This is not a must, but a near must for any API implementation. There are many documentation libraries available like Swagger, TRex and other API Management Gateways also provide good API documentation services.

#6 Authentication

Most public developer APIs are secured by the API keys. Ex – Google Maps. The key is often used not only in authentication but also in monitoring the request rates and etc. If the API is private (either to a single organization or few accepted parties) the recommended practice is to have an authentication. Mostly this is an OAuth 2 based authentication and there are several token formats whilst JWT being the well-known one.

With those concerns we can have a API implemented for the systems. There are many readings in based on the different aspects of the API, like documentation, hyper media, versioning, authentication, caching, scopes and etc. You can find ample amount of resources in the web sphere. This post gives the fundamental idea – separation of API and web application implementation. In the next post we will discuss more about implementing an API using the ASP.NET Core and EF Core stack.
